Description
On 3 Performance
2005 - 2013 C6 Corvette Single Turbo System
614-439-0057
Kit Includes: - On 3 Performance Complete 304 Stainless Header Package - On 3 Performance 304ss Thick Wall Crossover, t-4 Flanged - 3.0" to 3.5" Stepped Fender Exit Downpipe ( Rear Facing Downpipe Option Available) - Necessary V-Band Clamps for Hot-side - Custom Cast Turbo Merge Section / Turbo Mount Cold Side: - On 3 Performance Race Core, Bar and Plate 4.0" Air to Air Intercooler - Complete 5-ply Black Silicone Coupler Kit - Stainless Steel T-bolt Clamp Kit Components: - On 3 Performance 78/75 Turbocharger, .96ar, V-band Discharge, T4 Inlet - Dual On 3 Performance 44mm Wastegates (2pcs) - Complete Oil Feed & Drain Kit For Turbocharger - On 3 Performance Custom Urethane Air Filter / Adapter
Power expectations: Our test car here was a stock LS2 bottom end and top end with the On3 Boost cam. This combo made 600hp@9lbs if boost on 93 octane through an unlocked converter on a our mustang dyno. This car later on had a built 6.2l ls3 engine swapped into it, and converted to e85 by the guy who bought . We then turned it up and it made 780hp on 18lbs of boost where the 7875 cast wheel was starting to run out of steam. Soon we will be updating the results with our 88mm upgrade that he is installing this winter so we can turn it up farther.
Cooling System Details: First and foremost, the kit does require you to stand up the radiator with a custom kit(*Not Included). We are currently developing our own complete rear mounts radiator cooling system. We have plans to release this kit later in the winter months. So if you do not want to build your own cooling system, we have a tested package we are planning to release if this is going to be your winter project. If not, there are several places that sell kits and many people building their own unique systems.
AC System: We ship our kits with the bumper exit which essentially does allow your AC compressor to stay on the car. We did not keep the ac on our design car however you could make your own lines and run a custom condenser. We never did this so if you plan on attempted to maintain the AC, it would be completely at your discretion.
Coils / Wires: You will be required to move your coils and run custom wires, we now offer the upgraded coil relocation kit and spark plug wire set. This will only work on the factory aluminum blocks. The iron blocks have the mounting provision changed so if you wanted to run it with an iron block it will be up to you to modify the brackets potentially.
